OUR PRODUCTS
BODY
Aluminum with an elegant design and color options in white and black.
LENS
50° and 80° Angle Lens
CONVERTER
Long-lasting constant current converter compliant with ENEC standards.
LED
LUMILEDS / OSRAM / NICHIA brand LED modules with a lifespan of 60,000 hours.
SUSPENSION
Made of 1mm steel braided wire and nickel-plated brass parts, adjustable suspension length, with transparent power cable and aesthetically designed ceiling-mounted electrical connection box.
COLOR OPTIONS
White, Black
APPLICATION AREAS
Shopping Malls, Markets, Offices, Meeting Rooms, Living Rooms, Waiting Lounges, Stores, Hospitals, Schools, Corridors
OPTIONS
Dimmable DALI Driver, Emergency kit.
| Code | AC POWER (W) | Armature Output Flux (lm) | Width (mm) | Diameter / Length (mm) | Height (mm) | Weight (kg) | Ldt |
|---|---|---|---|---|---|---|---|
| PL10A11L15L | 10 | 970 | 53 | 287 | 50 | 1,2 | |
| PL10A12L15L | 16 | 1935 | 53 | 567 | 50 | 1,7 | |
| PL10A13L15L | 22 | 2900 | 53 | 847 | 50 | 2,3 | |
| PL10A14L15L | 29 | 3865 | 53 | 1127 | 50 | 2,9 | |
| PL10A15L15L | 37 | 4830 | 53 | 1407 | 50 | 3,5 | |
| PL10A16L15L | 44 | 5800 | 53 | 1687 | 50 | 4,1 | |
| PL10A17L15L | 52 | 6765 | 53 | 1967 | 50 | 4,7 | |
| PL10A18L15L | 60 | 7730 | 53 | 2247 | 50 | 5,3 | |
| PL10A19L15L | 66 | 8695 | 53 | 2527 | 50 | 5,9 | |
| PL10A10L15L | 75 | 9660 | 53 | 2807 | 50 | 6,5 |
