Galaksi Dolunay Direct / Indirect

BODY

Anodized aluminum with satin finishing. Black and white color options with elegant design.

CONVERTOR

Long life, low power loss converter with constant current. Compatible with ENEC standards.

LED

LED modules with 60.000 hours lifetime LUMILEDS / OSRAM / NICHIA brand LEDs.

SUSPENSION

Composed of 1mm steel wire rope and nickel-plated brass components. Suspension height is adjustable. Supplied with transparent electric cord and ceiling mounted electrical junction box with aesthetic design

COLOURS

White, Black

USED AREAS

Shopping Malls, Supermarkets, Offices, Meeting rooms, Stores, Hospitals, Schools, Corridors

OPTIONS

Dimmable DALI Driver, Emergency Kit

Code	AC POWER (W)	Armature Output Flux (lm)	Diameter / Length (mm)	Height (mm)	Weight (kg)	Ldt
PL8ESD36K12C	16 / 10	1740 / 1170	360	94	3,1	⬇️
PL8ESD36K13C	20 / 10	2145 / 1170	360	94	3,1	⬇️
PL8ESD36K14C	24 / 10	2455 / 1170	360	94	3,1	⬇️
PL8ESD47K12C	23 / 14	2815 / 1560	470	94	5,2	⬇️
PL8ESD47K13C	30 / 14	3450 / 1560	470	94	5,2	⬇️
PL8ESD47K14C	36 / 14	3995 / 1560	470	94	5,2	⬇️
PL8ESD60K12C	36 / 18	4420 / 1950	600	94	6,5	⬇️
PL8ESD60K13C	46 / 18	5420 / 1950	600	94	6,5	⬇️
PL8ESD60K14C	57 / 18	6300 / 1950	600	94	6,5	⬇️
PL8ESD90K12C	78 / 28	9865 / 3120	900	94	7,2	⬇️
PL8ESD90K13C	100 / 28	12075 / 3120	900	94	7,2	⬇️
PL8ESD90K14C	119 / 28	14000 / 3120	900	94	7,2	⬇️
PL8ESD120K12C	153 / 35	19125 / 3900	1200	94	9,3	⬇️
PL8ESD120K13C	200 / 35	24000 / 3900	1200	94	9,3	⬇️
PL8ESD120K14C	243 / 35	27945 / 3900	1200	94	9,3	⬇️
