OUR PRODUCTS
BODY
Aluminum with an elegant design and color options in white and black.
CONVERTER
Long-lasting, low-power, constant current converter compliant with ENEC standards.
LED
LED modules by LUMILEDS / OSRAM / NICHIA with a lifespan of 60,000 hours.
SUSPENSION
Made of 1mm steel braided wire and nickel-plated brass parts, adjustable suspension length, with transparent power cable and aesthetically designed ceiling-mounted electrical connection box.
COLOR OPTIONS
White, Black
APPLICATION AREAS
Shopping Malls, Markets, Offices, Meeting Rooms, Living Rooms, Waiting Lounges, Stores, Hospitals, Schools, Corridors
OPTIONS
Dimmable DALI Driver, Emergency kit.
| Code | AC POWER (W) | Armature Output Flux (lm) | Width (mm) | Diameter / Length (mm) | Height (mm) | Weight (kg) | Ldt |
|---|---|---|---|---|---|---|---|
| PL8AD23K12C | 23 | 2815 | - | 490 | 85 | 5,0 | |
| PL8AD30K13C | 30 | 3450 | - | 490 | 85 | 5,0 | |
| PL8AD36K14C | 36 | 3995 | - | 490 | 85 | 5,0 | |
| PL8AD36K12C | 36 | 4420 | - | 620 | 85 | 6,3 | |
| PL8AD46K13C | 46 | 5420 | - | 620 | 85 | 6,3 | |
| PL8AD57K14C | 57 | 6300 | - | 620 | 85 | 6,3 | |
| PL8AD78K12C | 78 | 9865 | - | 920 | 85 | 7,0 | |
| PL8AD100K13C | 100 | 12075 | - | 920 | 85 | 7,0 | |
| PL8AD119K14C | 119 | 14000 | - | 920 | 85 | 7,0 | |
| PL8AD153K12C | 153 | 19125 | - | 1220 | 85 | 9,1 | |
| PL8AD200K13C | 200 | 24000 | - | 1220 | 85 | 9,1 | |
| PL8AD243K14C | 243 | 27945 | - | 1220 | 85 | 9,1 |
