OUR PRODUCTS
BODY
Aluminum with elegant design and color options in white and black.
CONVERTER
Long-lasting constant current converter compliant with ENEC standards.
LED
LED modules by LUMILEDS / OSRAM / NICHIA with a lifespan of 60,000 hours.
SUSPENSION
Made of 1mm steel braided wire and nickel-plated brass parts, adjustable suspension length, with transparent power cable and aesthetically designed ceiling-mounted electrical connection box.
COLOR OPTIONS
White, Black
APPLICATION AREAS
Shopping Malls, Markets, Offices, Meeting Rooms, Stores, Hospitals
OPTIONS
Dimmable DALI Driver, Emergency kit.
| Code | AC POWER (W) | Armature Output Flux (lm) | Width (mm) | Diameter / Length (mm) | Height (mm) | Weight (kg) | Ldt |
|---|---|---|---|---|---|---|---|
| PL8AATO8L15C | 53 | 5170 | - | 820 | 84 | 6,5 | |
| PL8AATO10L15C | 66 | 6460 | - | 1000 | 84 | 7,2 | |
| PL8AATO12L15C | 79 | 8210 | - | 1175 | 84 | 9,3 | |
| PL8AATO14L15C | 92 | 9580 | - | 1355 | 84 | 10,5 | |
| PL8AATO16L15C | 105 | 10945 | - | 1520 | 84 | 11,7 | |
| PL8AATO20L15C | 132 | 13680 | - | 1910 | 84 | 12,9 | |
| PL8AATO24L15C | 158 | 16420 | - | 2275 | 84 | 14,1 |
