Galaksi O Trimless

BODY

Aluminum with elegant design and color options in white and black.

LED

LED modules by LUMILEDS / OSRAM / NICHIA with a lifespan of 60,000 hours.

SUSPENSION

Made of 1mm steel braided wire and nickel-plated brass parts, adjustable suspension length, with transparent power cable and aesthetically designed ceiling-mounted electrical connection box.

COLOR OPTIONS

White, Black

APPLICATION AREAS

Shopping Malls, Markets, Offices, Meeting Rooms, Stores, Hospitals

OPTIONS

Dimmable DALI Driver, Emergency kit.

Code	AC POWER (W)	Armature Output Flux (lm)	Width (mm)	Diameter / Length (mm)	Height (mm)	Weight (kg)
PL8AOT4L15C	26	2585	447	289	73	5.1
PL8AOT6L15C	39	3880	620	462	73	6.0
PL8AOT6L25C	61	5835	620	462	73	6.0
PL8AOT8L15C	53	5170	800	642	73	7.7
PL8AOT8L25C	80	7780	800	642	73	7.7
PL8AOT10L15C	66	6460	980	822	73	10.7
PL8AOT10L25C	100	9725	980	822	73	10.7
PL8AOT12L15C	79	8210	1155	997	73	12.7
PL8AOT12L25C	120	12315	1155	997	73	12.7
PL8AOT14L15C	92	10240	1335	1177	73	14.7
PL8AOT14L25C	140	15360	1335	1177	73	14.7
PL8AOT16L15C	105	11705	1500	1342	73	17.7
PL8AOT16L25C	160	17560	1500	1342	73	17.7
PL8AOT20L15C	132	14630	1890	1732	73	18.7
PL8AOT20L25C	200	21945	1890	1732	73	18.7
PL8AOT22L15C	145	16100	2070	1912	73	19.2
PL8AOT22L25C	221	24150	2070	1912	73	19.2
PL8AOT24L15C	158	17560	2254	2096	73	19.7
PL8AOT24L25C	240	26340	2254	2096	73	19.7

Galaksi O Trimless is a ring LED luminaire recessed into a plasterboard ceiling without a visible frame. It differs from the standard recessed model in leaving no trim edge: the luminaire is plastered flush into the surface, so only the light-emitting ring reads on the ceiling. That detail makes it a natural choice for hotel lobbies, retail display areas and executive floors where the ceiling should be read as an uninterrupted plane.

The product is manufactured in nineteen types. Power runs from 26 W to 240 W and luminaire output flux from 2,585 lm to 26,340 lm. The outer dimension is offered in ten steps from 447 mm to 2254 mm, while the inner opening of the ring runs from 289 mm to 2096 mm. From 620 mm upward every size carries two LED densities, L15C and L25C: at 1500 mm outer, for instance, PL8AOT16L15C gives 105 W and 11,705 lm while PL8AOT16L25C reaches 160 W and 17,560 lm. Body height is 73 mm and weight ranges from 5.1 kg to 19.7 kg.

Frameless installation requires the ceiling works to be planned together with the luminaire; in return the result is a pure ring of light carrying no additional detail. The aluminium body is offered in white and black. LED modules from LUMILEDS, OSRAM and NICHIA are rated at 60,000 hours. Suitable for shopping malls, markets, offices, meeting rooms, stores and hospitals. The ISO 9001-2015 certificate, the EC and UKCA declarations and the datasheet are on the product page. Dimmable DALI driver and emergency kit are optional; UGR<19 glare control and CRI 90 colour rendering can also be supplied on request.

All processes from design to production are carried out in our factory. This allows us to design products that combine aesthetics with competitiveness.
