Prizma Suspended 2X Lighting Fixtures With Frosted Diffuser

Prizma Suspended 2X is a twin-module LED pendant with a frosted diffuser. What distinguishes the range is body height: just 32 mm. Despite a broad 223 mm face, that dimension keeps the luminaire reading as barely projecting from the ceiling; a wide emitting surface and a slim section are achieved together.

The product is manufactured in eight codes across four lengths: 620, 900, 1180 and 1460 mm. Each length comes in two LED densities: the standard L15C and the denser L25C. The smallest type, PL4S22L15C, gives 26 W and 3,270 lm, while PL4S22L25C reaches 41 W and 4,905 lm in the same body. The largest, PL4S25L25C, gives 100 W and 12,255 lm at 1460 mm. Body width is 223 mm across every type; weight ranges from 2.6 kg to 4.8 kg. Efficacy sits in a band of roughly 123 to 126 lm/W.

The frosted diffuser conceals the individual LEDs and softens the light, which matters particularly on a wide-faced luminaire because dotting reads more strongly across a broad surface. The body is aluminium in a slim 32 mm elegant design, offered in white, silver and black. LED modules from LUMILEDS, OSRAM and NICHIA are rated at 60,000 hours; the converter is a long-life, ENEC-compliant constant current type. The suspension uses 1 mm braided steel wire and nickel-plated brass parts with adjustable drop.

Suitable for shopping malls, markets, offices, meeting rooms, stores, hospitals, schools, corridors, open-plan offices, reception areas, showrooms, libraries and bank branches. ISO 9001-2015 and TS EN IEC 60598-2-1 documents, together with the datasheet, technical drawing, EC declaration of conformity, UKCA certificate and an LDT file for each type, are on the product page. Dimmable DALI driver and emergency kit are optional; UGR<19 glare control and CRI 90 colour rendering can also be supplied on request.
