BODY
Electrostatic powder coated sheetmetal.
LENS
GLASS: 4mm tempered glass (with certificate)
CONVERTER
Long life, low power loss converter with constant current. Compatible with ENEC standards.
LED
LED modules with 60.000 hours lifetime LUMILEDS / OSRAM / NICHIA / SEOUL brand LEDs.
Suspension
SEAL: Thermoplastic elastomer
APPLICATION AREAS
Patient Rooms, Surgery Rooms, Consulting Rooms
OPTIONS
Dimmable DALI Driver, Emergency kit.
| Code | AC POWER (W) | Armature Output Flux (lm) | Width (mm) | Diameter / Length (mm) | Height (mm) | Weight (kg) | Ldt |
|---|---|---|---|---|---|---|---|
| PL12A11E06C | 14 | 1205 | 316 | 316 | 85 | 2,5 | |
| PL12A12E04C | 14 | 1770 | 316 | 616 | 85 | 3,5 | |
| PL12A12E05C | 20 | 2005 | 316 | 616 | 85 | 3,5 | |
| PL12A13E04C | 22 | 1900 | 316 | 916 | 85 | 4,5 | |
| PL12A13E05C | 32 | 2765 | 316 | 916 | 85 | 4,5 | |
| PL12A14E04C | 29 | 2515 | 316 | 1216 | 85 | 6,5 | |
| PL12A14E05C | 42 | 3640 | 316 | 1216 | 85 | 6,5 | |
| PL12A22E04C | 36 | 3185 | 616 | 616 | 85 | 8,0 | |
| PL12A22E05C | 42 | 3610 | 616 | 616 | 85 | 8,0 | |
| PL12A22E06C | 56 | 4550 | 616 | 616 | 85 | 8,0 | |
| PL12A24E04C | 72 | 6370 | 616 | 1165 | 85 | 16,0 | |
| PL12A24E05C | 84 | 7150 | 616 | 1165 | 85 | 16,0 | |
| PL12A24E06C | 112 | 9100 | 616 | 1165 | 85 | 16,0 |
