Vega Slim Surface Mounted

Vega Slim Surface Mounted is the variant of the linear Vega Slim profile that fixes directly to the ceiling surface. With no suspension components no ceiling height is given up and no additional support structure is needed on concrete soffits. Along long corridors and open-plan axes, units join end to end into an unbroken line.

The product is offered in thirty-three codes, the widest type range in the series. Lengths are 570, 850, 1130, 1412, 1693, 1973, 2254, 2534 and 2815 mm, with two LED densities, L15C and L25C, up to 1973 mm. PL13U12L15C opens the range at 14 W and 1,315 lm in 570 mm; PL13U17L25C reaches the highest power in the series at 70 W and 6,885 lm. Body width is 57 mm and height 85 mm; weight ranges from 1.3 kg to 4.5 kg.

From 1412 mm upward, variants with SB and SO suffixes are available. These hold the same power and flux figures while shortening the body by 4 and 8 mm, which allows joint allowances to be accounted for in continuous-run layouts. LDT and Revit files for each type are on the product page. The aluminium body is offered in white and black; the converter is a long-life, ENEC-compliant constant current type. LED modules from LUMILEDS, OSRAM and NICHIA are rated at 60,000 hours. Suitable for shopping malls, markets, offices, meeting rooms, living rooms, waiting lounges, stores, hospitals, schools, corridors, open-plan offices, airports and terminals, universities, libraries and public buildings. ISO 9001-2015, TS EN IEC 60598-2-1, EC and UKCA documents and the technical drawing are on the product page. Dimmable DALI driver and emergency kit are optional; UGR<19 glare control and CRI 90 colour rendering can also be supplied on request.
