LUNO ACOUSTIC

Product Details

Body
Anodized aluminum with satin finishing. Black and white color options with elegant design.
Convertor
Long life, low power loss converter with constant current. Compatible with ENEC standardss
Led
LED modules with 60.000 hours lifetime LUMILEDS / OSRAM / NICHIA brand LEDs.
Suspension
Composed of 1mm steel wire rope and nickel-plated brass components. Suspension height is adjustable. Supplied with transparent electric cord and ceiling mounted electrical junction box with aesthetic design
Areas
Shopping Centers, Markets, Offices, Meeting rooms, Shops, Hospitals
Options
Dimmable DALI Driver, Emergency Kit.

LUNO ACOUSTIC
PANEL ACOUSTICS
SOFT ACOUSTICS

Code	AC POWER (W)	Armature Output Flux (lm)	Width (mm)	Diameter / Length (mm)	Height (mm)	Weight (kg)
PL1SAO4L15C	26	2585	79	447	73	5,1
PL1SAO6L15C	39	3880	79	620	73	6,0
PL1SAO6L25C	61	5835	79	620	73	6,0
PL1SAO8L15C	53	5170	79	800	73	7,7
PL1SAO8L25C	80	7780	79	800	73	7,7
PL1SAO8L25C	66	6460	79	980	73	10,7
PL1SAO10L25C	100	9725	79	980	73	10,7
PL1SAO12L15C	79	8210	79	1155	73	12,7
PL1SAO12L25C	120	12315	79	1155	73	12,7
PL1SAO14L15C	92	10240	79	1335	73	14,7
PL1SAO14L25C	140	15360	79	1335	73	14,7
PL1SAO16L15C	105	11705	79	1500	73	17,7
PL1SAO16L25C	160	17560	79	1500	73	17,7
PL1SAO20L15C	132	14630	79	1890	73	18,7
PL1SAO20L25C	200	21945	79	1890	73	18,7
PL1SAO22L15C	145	16100	79	2070	73	19,2
PL1SAO22L25C	221	24150	79	2070	73	19,2
PL1SAO24L15C	158	17560	79	2254	73	19,7
PL1SAO24L25C	240	26340	79	2254	73	19,7
