PANEL ACOUSTICS

Product Details

Body
Anodized aluminum with satin finishing. Black and white color options with elegant design.
Lens
With 50° or 80° lens.
Convertor
Compatible with ENEC standards.
Led
LED modules with 60.000 hours lifetime LUMILEDS / OSRAM / NICHIA brand LEDs.
Suspension
Composed of 1mm steel wire rope and nickel-plated brass components. Suspension height is adjustable.
Colours
White, Black
Areas
Offices, Meeting rooms, Stores, , Schools, Corridors
Options
Dimmable DALI Driver, Emergency Kit.

LUNO ACOUSTIC
PANEL ACOUSTICS
SOFT ACOUSTICS

Code	AC POWER (W)	Armature Output Flux (lm)	Width (mm)	Diameter / Length (mm)	Height (mm)	Weight (kg)
PL3SAE12L15L	16	1935	47	578	73	1,2
PL3SAE13L15L	22	2900	47	858	73	2,3
PL3SAE14L15L	29	3865	47	1138	73	2,3
PL3SAE15L15L	37	4830	47	1418	73	2,9
PL3SAE16L15L	44	5800	47	1698	73	3,5
PL3SAE17L15L	52	6765	47	1973	73	4,0
PL3SAE18L15L	60	7730	47	2258	73	4,6
PL3SAE19L15L	66	8695	47	2538	73	5,2
PL3SAE10L15L	75	9660	47	2818	73	5,7
