SOFT ACOUSTICS

Product Details

Body
Anodized aluminum with satin finishing. Black and white color options with elegant design.
Convertor
Long life, low power loss converter with constant current. Compatible with ENEC standards.
Led
LED modules with 60.000 hours lifetime LUMILEDS / OSRAM / NICHIA brand LEDs.
Suspension
Composed of 1mm steel wire rope and nickel-plated brass components. Suspension height is adjustable. Supplied with transparent electric cord and ceiling mounted electrical junction box with aesthetic design
Areas
Shopping Malls, Supermarkets, Offices, Meeting rooms
Options
Dimmable DALI Driver, Emergency Kit.

LUNO ACOUSTIC
PANEL ACOUSTICS
SOFT ACOUSTICS

Code	AC POWER (W)	Armature Output Flux (lm)	Width (mm)	Diameter / Length (mm)	Height (mm)	Weight (kg)
PL5SAS12L15C	14	1445	40	570	76	1,4
PL5SAS12L25C	21	2170	40	570	76	1,5
PL5SAS13L15C	21	2170	40	850	76	1,8
PL5SAS13L25C	30	3250	40	850	76	1,8
PL21S14L15C	26	2890	40	1130	76	2,3
PL5SAS14L25C	41	4335	40	1130	76	2,3
PL5SAS15L15C	33	3610	40	1410	76	2,8
PL5SAS15L25C	51	5415	40	1410	76	2,8
PL5SAS16L15C	39	4335	40	1693	76	3,3
PL5SAS16L25C	61	6500	40	1693	76	3,3
PL5SAS17L15C	47	5055	40	1973	76	3,8
PL5SAS17L25C	70	7585	40	1973	76	3,8
PL5SAS18L15C	53	5780	40	2254	76	4,3
PL5SAS19L15C	60	6500	40	2534	76	4,8
PL5SAS10L15C	66	7220	40	2815	76	5,3
